What’s In The Box 1 pair of woofers 1 pair of tweeters 1 pair of speaker grilles 1 pair of crossovers 1 pair of woofer mounting brackets 1 pair of tweeter surface mount accessories 1 pair of tweeter flush mount accessories 1 pair of tweeter nuts 1 pair of tweeter flat washers 6 tweeter mounting screws 8 woofer mounting screws 8 crossover mounting screws 8 speed clips Foam mounting tape Owner’s manual General Specifications DESCRIPTION: 6-1/2″ (160MM) COMPONENT SPEAKER SYSTEM POWER HANDLING: 90W RMS, 270W PEAK SENSITIVITY (@ 2.83V): 93DB FREQUENCY RESPONSE: 53HZ – 21KHZ IMPEDANCE: 3.0 OHMS Features Edge-driven, textile tweeters The audiophile-grade tweeters used in Infinity’s new Reference speakers deliver smooth, non-fatiguing sound even at high output levels. Adjustable tweeter output level The larger Reference multi-element and component systems offer a tweeter output level control to optimize system linearity to suit installation location or the listener’s preference. Plus

1 x Pair of woofers 1 x Pair of tweeters 1 x Pair of speaker grilles 1 x Pair of crossovers 1 x Pair of woofer mounting brackets 1 x Pair of tweeter surface mount accessories 1 x Pair of tweeter flush mount accessories 1 x Pair of tweeter nuts 1 x Pair of tweeter flat washers 6 x Tweeter mounting screws 8 x Woofer mounting screws 8 x Crossover mounting screws 8 x Speed clips 1 x Foam mounting tape 1 x Owner’s manual

Product Details New Infinity Reference amplifiers deliver pure power from a slim, compact chassis that’s designed to fit in more vehicles. Available in 4-channel, 5-channel, and mono models, Reference amps incorporate our latest amplifier topology, include variable electronic crossovers and bass boost control for precise system tuning, and feature high- and low-level inputs for easy interface with virtually any system. They’re also compatible with several new vehicle technologies, including many advanced driver assistance systems, and Harman HALOsonic, a suite of acoustic solutions that can simulate engine sounds for a better driving experience in hybrids and electric cars, cancel road noise for better-sounding music, and more. What’s in the box? 1 amplifier High-level input wiring harness 2 spare fuses 2 2-color brand stickers Quick start guide WARRANTY PERIOD: ONE YEAR

1 x Pair of 3-way speakers 1 x Pair of speaker grilles 1 x Pair of spacers 8 x Mounting screws 8 x Speed clips 1 x Foam mounting tape 1 x Owner’s manual

General Specification: Signal-to-Noise Ratio Max Power ≥85dB (ref 1W output @ 4Ω) 1000W Peak System Specification: Power Output, 2Ω Power Output, 4Ω Power Output, 4Ω Bridged 100W RMS x 4, <1.0% THD+N 70W RMS x 4, <1.0% THD+N 200W RMS x 2, <1.0% THD+N Compact footprint Infinity Reference amplifiers are designed with a compact chassis and small footprint to ease installation, even if available space is limited. High- and low-level inputs Speaker-level and low-level inputs allow Reference amps to work with just about any car stereo, aftermarket or factory. Variable crossovers and bass boost Unlike many amplifiers available at similar prices, Reference amps feature variable electronic crossovers and bass boost circuit to allow for fine-tuning. ADAS input with channel assignment In vehicles with ADAS warning systems, you can assign a channel to broadcast system alert messages. HALOsonic mixing input Reference amps can also work with the HALOsonic systems of select

mono subwoofer amplifier 370 watts RMS x 1 at 4 ohms (550 watts RMS x 1 at 2 ohms) Class D amp technology variable low-pass filter (32-320 Hz, 12 dB/octave) variable bass boost (0-9 dB at 45 Hz) phase switch (0, 180 degrees) preamp and speaker-level inputs fuse rating: 30A x 2 8-gauge power and ground leads recommended — wiring and hardware not included with amplifier 9-3/8″W x 2-1/4″H x 7-5/16″D

General Specifications POWER HANDLING: 80W RMS, 240W PEAK SENSITIVITY (@ 2.83V): 88DB FREQUENCY RESPONSE: 53HZ – 20KHZ VOICE COIL DIAMETER: 1 IN. (25MM) IMPEDANCE: 2.7 OHMS FEATURES PATENTED PLUS ONE™ POLYPROPYLENE WOOFERS POLYPROPYLENE CONES WITH UP TO 35% MORE RADIATING CONE AREA THAN OTHER CONES IN THE SAME CLASS PROVIDE HIGHER SENSITIVITY, INCREASED LOW FREQUENCY OUTPUT AND BETTER TONAL BALANCE. HI-ROLL RUBBER SURROUNDS USING AUTOMOTIVE GRADE MATERIALS RESULT IN CLEANER REPRODUCTION AND HIGHER DURABILITY WHETHER IT’S EASY LISTENING OR TIME TO SHOW AND SHINE. EDGE-DRIVEN TWEETERS EDGE-DRIVEN TWEETERS DELIVER WIDER DISPERSION AND SMOOTHER HIGH FREQUENCY RESPONSE WITH INCREASED POWER HANDLING FOR HIGH- AND MID-FREQUENCIES. TRUE 4 OHM ARCHITECTURE TRUE 4 OHM ARCHITECTURE WITH LOW IMPEDANCE VOICE COILS GIVE THE AMPLIFIER ROOM TO DELIVER PEAK POWER PROVIDING STRONGER AND CLEARER SOUND WITH BETTER DEPTH AND DETAIL. HARMAN STANDARD RELIABILITY TESTING INFINITY SPEAKERS HAVE TO UNDERGO A TESTING PROCESS THAT WOULD DESTROY

Operating voltage 9 – 16V RMS Power Rating 4 ohms 90W 2 ohms 110W RMS bridged power @ 4 ohms – 220W Total peak power 880W Frequency response – THD + N at rated power (20Hz – 20kHz)<1% Line-in signal-to-noise ratio (reference to 1 watt)>75dB Maximum high input signal level 12V High input maximum sensitivity 0.5V Maximum line input signal level 5V Line input maximum sensitivity 0.2V Quiescent current draw<1.5A Fuse size 2 x 20A

2 x Speakers 2 x Grilles 8 x Screws 8 x Speed clips 2 x Infinity logo badge
